    Shouya Edge Al HUB

    Built on end‑side micro‑board, this offline intelligent customer‑service system adopts locally fine‑tuned LLM and knowledge base. It integrates local ASR, TTS and semantic understanding for stable network‑free voice interaction.

    Shouya Edge Al HUB
    Lightweight hardware carrier
    With high-performance end side micro board as the core physical carrier, the complex AI algorithm is highly integrated with the inference engine, greatly reducing the deployment threshold, and providing a solid local computing base for intelligent applications.
    Integrated project delivery
    The one-stop delivery mode of "hardware+software+model" is adopted to deeply couple the pre training model with business logic. The installation and use deployment mode effectively shortens the project implementation cycle and improves the implementation efficiency.
    Principle of safety autonomy
    Adhere to localization of core competence and closed-loop data processing. Avoid external dependence from the source of architecture design, ensure the independence and stability of system operation, and fundamentally solve the problem of data privacy security.

    Functional core features

    Automation services

    The system has a built-in big model question and answer engine, which greatly improves the response efficiency. For complex problems that cannot be solved, the system will automatically record a complete question log to provide accurate data support for subsequent service process optimization and knowledge base iteration.

    Full dimensional barrier free design

    Create inclusive experience from four dimensions of vision, hearing, operation and cognition. Support large font, high contrast mode and screen reader adaptation; Provide real-time display of voice to text; Interface elements adapt to keyboard navigation and voice control; The operation process is extremely simple and intuitive, eliminating the use barriers of users with different abilities, and reflecting humanistic care.

    Multimodal fusion interaction

    Break the single interaction limit, and deeply integrate multiple input methods such as voice commands, touch screen touch control, physical entity keys, etc. Different interaction channels complement each other. The system can intelligently recommend the best way according to environmental noise, light conditions and user status, and can provide a stable and efficient operating experience in driving, handheld, emergency and other scenarioses.

    Adaptive personalized experience

    Continuous learning based on user behavior big data, actively adapting to users' pronunciation characteristics, word preference and operation habits, and dynamically optimizing recognition and recommendation models. At the same time, it supports users to customize common functions, interface layout and notification methods, transforming common services into a unique experience of thousands of people and faces, so that each interaction can understand users better.

    Animal tooth end side AI-HUB parameter information

    01

    DC Power: DC 12V adapter power supply interface
    TYPEC: One complete TYPEC interface, compatible with system firmware upgrade channel and DP1.4 output interface
    USB2.0 HOST1: One USB2.0 standard ‑ A interface, which can be connected to mouse, USB flash disk, USB HUB and other devices
    USB2.0 OTG: One USB2.0 standard ‑ A interface supports the OTG function, and can be connected to PC, mouse, USB flash disk, USB HUB and other devices
    USB3.0: HUB (connected to 1xUSB3.0 HOST seat, 3 connected to RK182X)
    MIPI D/CPHY RX: support two-way 4lane MIPI DPHY or two-way 3Trio MIPI CPHY signal input, accessed through 80pin seat
    MIPI DPHY RX: supports two-way 4lane or two-way 2lane MIPI signal input, accessed through 80pin seat. The function of photographing and video recording can be realized through the matching small board RK_EVB_RK3588_EXTBOARD1_IMX415_V11_20211027
    HDMI2.1 OUT: two-way HDMI2.1 OUT standard ‑ A interface, single channel maximum support 8K@60Hz Output
    HDMI2.0 IN: One way HDMI IN standard ‑ A interface, maximum support 4K@60Hz Video input
    MIPI DPHY0/1 TX: support two-way 4lane MIPI signal output, connected through FPC line
    WIFI (2T2R MIMO): The WIFI model is AP6398, with an external SMA antenna, supporting wireless Internet access
    Ethernet: support 1-way RJ45 interface 10/100/1000M Ethernet
    Audio Interface: support speaker, headphones output sound, single MIC recording
    SATA3.0 Interface: One way 7pin SATA interface
    PCIe 3.0 Interface: a standard PCIex2 interface for extending PCIe devices
    RK182X: 2 × RK182X SODIMM module, RK182X M2 module (one PCIE2.0, one PCIE3.0, one RGMIIO)
    UART Debug: users debug and view LOG information; Support TYPEC and MINI USB interface
    JTAG: system JTAG debugging interface
    System Key: including Reset, PWRON, RES and BOOT keys
    SPDIF: support digital audio interface
    RTC: HYM8563TS chip is adopted, which can be powered by development board or button battery (CR1220 ‑ 3V)

    Start your journey of intelligence

    Our industry experts can provide you with targeted consultation on intelligent hardware solutions to help upgrade products intelligently
